THW‑LS/THHW‑LS 14 AWG Black Cable 100 m CDC

THW‑LS/THHW‑LS 14 AWG Black Cable 100 m CDC is a high-performance PVC-insulated copper cable designed to meet stringent safety and operational standards for industrial, commercial, and residential installations. This cable, sold in a convenient 100-meter coil, features stranded copper conductors (19 strands) and low-smoke, low-halogen PVC insulation, labeled THW‑LS/THHW‑LS 14 AWG Black Cable 100 m CDC throughout its length to enable easy identification and specification compliance.

The THW‑LS/THHW‑LS 14 AWG Black Cable 100 m CDC offers excellent durability under tough conditions. Insulation is rated to resist flames and produce minimal smoke and corrosive gas (LS), meeting NMX‑J‑010‑ANCE, NEC, and UL standards (B3, B8, B787, UL1581, UL83). The cable is approved for 600 V service and can handle temperatures up to 90 °C in dry locations (THHW‑LS) and 75 °C in wet or oily environments (THW‑LS).

H2 Features

• Stranded copper conductor (14 AWG, 19 strands) for flexibility and reliability (≈5.26 mm²)

• Low-smoke, flame-retardant PVC insulation with nylon jacket for heat, moisture, and abrasion resistance

• Bold black coloring, ideal for concealed wiring and aesthetic cable runs

• 600 V rated conductor, suitable for building branch circuits and industrial applications

• Operational temperatures: 90 °C in dry, 75 °C in wet/oil environments

• Roll of 100 m, box packaging following CDC (Comisión Federal) standards

H2 Technical Specifications

H2 Applications

The THW‑LS/THHW‑LS 14 AWG Black Cable 100 m CDC is engineered for a wide range of electrical installations:

• Power and lighting circuits in commercial and industrial buildings

• Raceway and conduit wiring for pumps, motors, and heating systems

• Control wiring in factories, service panels, and switchboards

• Plenum and tray installations with fire safety needs

• OEM machinery and equipment cable harnessing

H2 Installation & Maintenance

1. Uncoil carefully—avoid sharp bends; maintain recommended bend radius

2. Use proper cutting and stripping tools to prevent conductor damage

3. Secure in conduit, trays, or cable management systems

4. Support at intervals per electrical code to prevent sagging

5. Avoid exposure to chemicals, excessive UV, or physical damage

6. Inspect insulation for cracks annually and replace damaged sections

H2 Benefits

• Safety-first design: low smoke, flame retardant, meets major standards

• Durable construction: strong copper and robust insulation

• Flexible handling: stranded conductor reduces breakage during routing

• Wide use case: fits residential, industrial, commercial environments

• Regulatory approved: CDC box length aligns with regional codes

H2 Why Choose This Cable?

By selecting THW‑LS/THHW‑LS 14 AWG Black Cable 100 m CDC, you ensure compliance with international and Mexican standards while benefiting from reliable performance and ease of installation. The cable’s proven track record—backed by technical specs and certifications—makes it a trusted option for professionals demanding both quality and safety.
